The key parameters for a smart glass greenhouse are crucial for ensuring optimal growing conditions and efficient operation. Here are the main parameters and design specifications:
Environmental Control Parameters
1. Temperature
Range: Typically maintained between 18°C to 28°C for most crops, but can be adjusted based on specific plant requirements.
Control Systems: Heating systems (such as hot water or steam heating), cooling systems (like wet curtain and fan systems), and insulation systems to maintain the desired temperature.
2. Humidity
Range: Generally kept between 60% to 80% relative humidity, but can vary depending on the crop.
Control Systems: Humidifiers and dehumidifiers, as well as ventilation systems to manage moisture levels.
3. Lighting
Light Transmission: Single-layer float glass transmits over 90% of light, while double-layer hollow glass transmits over 80%.
Control Systems: External and internal shading systems to regulate light intensity, and supplemental lighting systems (such as LED grow lights) for extended daylight hours or low-light conditions.
4. CO₂ Concentration
Range: Typically maintained around 400-1000 ppm, depending on the crop and growth stage.
Control Systems: CO₂ generators to increase CO₂ levels for enhanced photosynthesis.Smart glass greenhouses represent a significant leap forward in modern agriculture.
Structural and Design Parameters
1. Frame Material
Material: High-quality hot-dip galvanized steel structure with a zinc coating of 275g/m², providing a service life of over 20 years.
Design: A-type roof structure for stability and efficient drainage.
2. Covering Material
Types: Hollow tempered glass or single tempered glass, offering high light transmittance, durability, and safety.
Features: Tempered glass is known for its strength and safety, shattering into blunt particles if broken.
3. Span Width and Dimensions
Span Width: Common widths include 6.4m, 8m, 9.6m, 10.8m, 12.8m, or customized to meet specific needs.
Column Spacing: Typically 4.0m or 8.0m.
Shoulder Height: Ranges from 3.0m to 6.0m or customized.
4. Drainage and Ventilation
Drainage Capacity: Maximum drainage capacity of 140mm/h to handle heavy rainfall.
Ventilation Systems: Top window systems, fan systems, and wet curtain systems for effective air exchange and temperature control.
Additional Systems and Features
1. Shading Systems
External Shading: To reduce heat and glare during summer, ensuring optimal light diffusion.
Internal Shading and Insulation: To prevent heat loss and adjust sunlight intensity.
2. Irrigation and Fertilization
Automated Irrigation: Precision irrigation systems to ensure consistent water supply.
Fertilization Systems: Automated nutrient delivery systems to provide optimal nutrition to plants.
3. Monitoring and Control Systems
Sensors: Real-time monitoring of temperature, humidity, CO₂ levels, and light intensity.
Central Control Unit: PLC-based control systems for automated adjustments based on sensor data.
Cost Analysis for a 500-Square-Meter Smart Glass Greenhouse
Frame and Structure: $100,000 - $150,000
Covering Materials: $50,000 - $70,000
Environmental Control Systems: $30,000 - $50,000
Installation and Labor: $20,000 - $30,000
Total Estimated Cost: $200,000 - $300,000
These smart glass greenhouse parameters and costs provide a comprehensive overview of what is required to set up and operate a smart glass greenhouse, ensuring optimal conditions for high-yield and year-round crop production.
