Multi-Span Glass Greenhouse Key Strengths & Technical Highlights

Multi-Span Glass Greenhouse

Key Strengths & Technical Highlights



1. Superior Light Transmission

   • Ultra-clear tempered glass (≥91 % light transmission) guarantees uniform PAR distribution across every plant tier, boosting photosynthetic efficiency by up to 18 % compared with standard coverings.

   • Optional low-iron diffused glass scatters light evenly, reducing shadow zones and leaf burn in high-radiation regions.



2. Maximum Space Utilization

   • Wide-span gutter-connected design eliminates internal walls, increasing usable floor area by 30 – 40 %.

   • 6–9 m gutter height plus optional 1–2 m raised gutter extensions allow multi-layer cultivation and tall vine crops without structural compromise.



Multi-Span Glass Greenhouse   Key Strengths & Technical Highlights



3. Year-Round Climate Control

   • Ridge and side vent configurations (rack-and-pinion or push-pull drives) achieve 5–8 air exchanges per minute for rapid cooling.

   • Integration-ready for heating (hydronic, gas, biomass), evaporative cooling, fogging, CO₂ dosing and full LED/HPS supplemental lighting.



4. Structural Reliability & Longevity

   • Hot-dip-galvanized steel frame rated to ≥140 km/h wind loads and ≥25 kg/m² snow load, compliant with EN 13031-1 or AS/NZS 1170.

   • 25-year life expectancy for aluminum glazing profiles and stainless fasteners; 10-year hail & corrosion warranty.



5. Energy & Water Efficiency

   • Double or triple gutter condensation recovery system reclaims up to 3 L m⁻² day⁻¹ for irrigation, cutting fresh-water demand by 30 %.

   • Optional double-pane insulated glass reduces heating demand by up to 35 % in cold climates.



6. Modular Turnkey Solutions

   • Our company delivers complete glass greenhouse packages—from foundation and steel erection to glazing, climate computers, fertigation units and post-harvest areas—under a single contract.

   • CAD/BIM-based engineering ensures fast on-site assembly with multilingual construction guidance and remote support, cutting commissioning time by 20 %.



7. Tailor-Made Options

   • Roof vents, insect nets, blackout/photoperiod curtains, semi-closed systems, and rooftop solar integration available on request.

   • Suitable for high-value crops: tomatoes, cucumbers, leafy greens, berries, flowers and medicinal plants.



In short, our Multi-Span Glass Greenhouse combines maximum crop performance with decades of dependable operation. We provide every component plus expert construction guidance, delivering a true turn-key solution that lets growers start producing faster, safer and more profitably.
